Popular Articles
Gantom Pro Cable Pinout
Trunk Cable Wire Color Wire Gauge Pinout Red 16 AWG Power VDC + Blue 16 AWG Power GND Green 22 AWG DMX + Yellow 22 AWG DMX - Shield Shield DMX COM Branch Cable Wire Color Wire Gauge Pinout Red 22 AWG Power VDC + Blue 22 AWG Power ...
Gantom DMX 5 Pin to TRS & DC Barrel Wiring Diagram
Troubleshooting Tips
My fixture is blinking. Gantom fixtures have a variety of blinks. All DMX fixtures will flash a sequence of colored blinks to indicate it’s address when power is cycled (blue = 1s, green = 10s, red = 100s) Some fixtures have built in effects macros. ...
Looking for "4HU8" or "E347051"
"4HU8" or "E347051" are both UL related codes and are not specific to any one particular fixture model (you will see this information on ALL of our lights). If you have an old light you need to identify, you can easily look at our lights to match it ...
Ping Trim Kit Installation Guide
PM67 - Ping Swivel Mount w/Collar for 30mm and 40mm Fixtures - Anodized Black Finish Compatible products: Precision Z Spot and Flood (DMX), Gantom iQ(x), Gantom DMX V2 Mounting Hole Ø 80mm (3.15") - 90mm (3.5") Mounting Depth - Gantom DMX V2 80mm min ...
